You can get the modified firmware with telnet enabled at:
http://www24.zippyshare.com/v/98762212/file.html

Modifyed firmware info:
-add /etc/init.d/S90telnetd script to bring up telnetd at startup
-add user "admin" with pass "password" to /etc/passwd

Offset analysis from original file:
flashe9k.2.4.091009.68.EU.prod.img

Offset 0x0 -> 0xf Image file checksum "93 AD 3D CE CC 35 1D 4D 02 F7 CA 91 56 56 10 8B"
Offset 0x10 -> 0x763 Versioninformation and Configuration data for Bootloader Stage 1
Offset 0x20026 -> 0x2ea79 Bootloader Stage 2 ??
Offset 0x40026 -> 0x71425 romfs filesystem, version 1, named YAMON_XRPC
Offset 0x80026 -> 0x8dc25 romfs filesystem, version 1, named SPLASH_ROMFS
Offset 0xa0026 -> 0x380825 romfs filesystem, version 1, named KERNEL_ROMFS
Offset 0x3a0026 -> 0x1478025 root filesystem Linux cramfs, little endian version #2
Offset 0x1f00026 -> 0x1f0146a /wdev configfilesystem Linux jffs2 little endian

System: Sigma Designs SMP863x

Debrick information:
http://kb.netgear.com/app/answers/detail/a_id/9801
http://kb.netgear.com/app/answers/detail/a_id/9796

To do any changes in the root file system you have to mount the cramfs
at offset 0xa0026, copy its content, modify it and buid it new by
using mkfs.cramfs. Due to the limitations of cramfs it's not possible
to any changes directly.
To do changes in the /wdev jffs2 filesystem you have to mount it trough
the mtdblock device, copy its content and build it up with mkcramfs.
After pasting the raw fs data at the correct offsets make sure the
image file has a size of 33734844 byte. Delete the first 16 byte (the checksum),
save the file and build a md5 checksum over the whole image file. Edit the image
file and past the correct md5 sum at the beginning of it. Upload
the image file the the EVA9150 by using the FW interface. If you get a
message like "the version is not downgradable" you have a wrong md5 sum.
